Product Specification

• Interface:
  • PoE Ports: 1-4: 10/100/1000Mbps RJ45 Ports
  • Uplink Ports: 5-6: 1000Mbps RJ45 Ports



• Total Power Supply: 65W



• LED Indicator: Power, Link/Act



• Processing Types:
  • Store-and-Forward
  • Half-duplex back pressure and IEE802.3x full-drplex flow control



• Performance Specification:
  • Bandwidth: 12Gbps
  • Packet Forwardind Rate: 8.93Mpps
  • MAC Address: 2k



• Network Standards:
  • IEEE802.3i 10BASE-T
  • IEEE802.3u 100BASE-TX
  • IEEE802.3ab 1000 BASE-T
  • IEEE802.3x Flow Control
  • IEEE802.3az EEE



• Power Inout: AC 200-240V 50/60Hz ( Power cable supplied)



• Size: 200mm(L) x 133mm(W) x 44mm(H)



• Cables: UTP category 5 or above cable



• Environmental specification:
  • Working temperature: 0C - 45C, Humidity: 10%-90% non-condensing
  • Storage temperature: 20C - 70C, Humidity 5% - 95% non-condensing
