CED SF32N Switchfuse Isolator 32A TPN 415V Complete with Fuses
Product Features:
- Lockable Handle
- Complies to low voltage directive 73/23/EEC and takes BS88 Part 2 - Fuses
- Fuses fully isolated (top & bottom) for safe replacement
- Allows for quick, safe manual deactivation of a circuit for maintenance.
- High breaking capacity untilising HRC fuses
| Ambient Humidity | Max 50% at 40°C, 90% at 20°C (As per standard) |
| Ambient Temperature (°C) | 40°C |
| Anti-Surge (Y/N) | N |
| Applications | Industrial |
| Approvals/Certifications | CE, UKCA |
| Body material | Enclosure- CRCA; Switch Body-DMC |
| Breaking Capacity | 80 KA |
| Class | I |
| Colour/Finish | Enclosure- RAL 5008 (Blue/Grey Semi Glossy) |
| Current (amps) | 32 |
| Dimensions (mm) | 275 x 275 x 180 |
| Frequency (Hz) | 50/60 |
| Ingress Protection (IP) | IP54 |
| Input Voltage (Hz) | 415 |
| Knockouts | 20mm; 25mm; 20mm |
| Mounting | Wall |
| Number Earth Terminals | 2 |
| Number of Knockouts | 3 |
| Number of Poles | TPN |
| Operating Temperature | 0-40°C |
| Phase | 3 |
| Switch type | Rotary Lockable |
| Terminal Capacity (mm²) | 6 |
| Torque (Nm) | 2N-m |
| Warranty Period (Years) | 1 |
