Product Details

• Plate Dimensions: (mm) 86 (W) x 86 (H) x 9.5 (D)

• Plate Fixing Centres: - Horizontal (mm) 60.3

• MiniGrid Plate (Gang): 1

• Style: Rounded Profile

• Colour: Polar White

• Materials:
  • Front Plate & Rocker Switch: Urea
  • FCU Front: Nylon

  • Rear Housing: Nylon
  • Terminals: Brass

  • Terminal Screws: Steel & Yellow Passivated
  • Contacts: Silver “on-lay” Copper / Brass

  • Internal Busbars: Formed Pressed Brass
  • Fuse: BS 1362 (3A)

• Anti Microbial: Certified Yes

• Operating Voltage (AC): 250 Frequency (Hz) 50

• Resistive Load Rating (A): 10

• Fuse Fitted Type: Plug Top Cartridge Fuse

• Termination Type: Screw

• Terminal Size (mm): Ø3.5 Terminal Torque Value (Nm) 0.4

• Terminal Capacity - Solid (mm²): 4 x 1.5 or 2 x 2.5

• Modular Rocker Switches: Yes

• Triple Pole Switch: Yes

• Product Marking: Isolator, On, Off’, Fuse

• Minimum Back Box Depth (mm): 25

• Ingress Protection: IP20

• Operational Temperature (°C): -5 to +40

• Warranty (Years): 25

• Standards: BS EN 60669-2-4, BS EN 60669-1, BS 5733, BS 1362
