Collingwood DLT551500A H2 Lite CSP Dual Wattage, CCT Downlight
PRODUCT OVERVIEW
| Warranty | 7 years |
|---|---|
| CRI | CRI>80 |
| UGR | 25 |
| IP Rating | IP65 (from below) IP20 (from above) |
| Dimmable Option | Mains (Leading Edge/Trailing Edge) |
| Adjustability | Not adjustable |
| Input | 220-240V AC |
| Ambient Temperature | 40°C |
| Insulation Coverable | Rolled and blown insulation |
| Cut Out | 68-72 |
| Body Material | Mild steel |
| Bathroom Zone | 1 |
| Electric Class | 2 |
| Suitable for coastal areas | No |
| Beam Angle | 55° |
| Building Regulations | Part B, C, E, P & L |
| Ceiling Joist Approvals | Solid Timber 30/60/90min, I-Joist 30min, Metal Web 30min |
| Colour / Finish | |
| CCT Range | 2700K / 3000K / 4000K |
| lm/W Range | 107-124 (4.2W) / 104-120 (6W) |
| LED Lifetime | L70 40,000h |
| Power Factor | 0.85 |
| Install Connector Type | 2 part first fit connector |
| Energy Class | D |
| Width | 84.7 |
| Length | 84.7 |
| Height | 55 |
| Style | Single unit |
| Sensor Option | None |
| Emergency Option | None |
| Tiltable | No |
| Rotation Angle | No |
| Wattage & Lumens | Lumens: 450-520 (4.2W) / 625-720 (6W)lm , Wattage: 4.2-6W |
