Eaton EMBH132 32A, 10kA, Type B Single Pole MCB
Product Description
- Terminal Type: Box clamp
- Current Rating: 32A
- Terminal Capacity: 1 -25mm²
- Terminal Screw: M5 Combination
- Terminal Torque: 2.0Nm - 2.4Nm max
- Mounting: DIN rail
- Degree of Protection: IP20
- Positive Contact Indication: Red/Green flag indicator
- Rated Volume: 230/240 V AC, 48V DC (per pole)
- Rated Impulse and Withstand VOltage: 4kV (1.2/50) u sec
- Rated Short Circuit Capacity: 10kA to IEC EN 60898 and 15kA to IEC EN 60947-2
- Selectivity Class: 3 to EN 60898
- Instanteneous Tripping Current: 3 In < Imt< 5 In
- Conventional Non-Tripping Current: I nt = 1.45 In
- Ref/Ca;ibration Temperature: 40° C
- Number of Operating Cycles Elec: >4000
- Number of Operating Cycles Mech: >2000
Specification
Amps ii |
32 |
Depth |
60mm |
Gtin |
5019586121547 |
Height |
80mm |
Product type |
Commercial MCBs |
Width |
18mm |
