Eaton EMCH163 63A, 10kA, Type C Single Pole MCB

Eaton EMCH163 63A, 10kA, Type C Single Pole MCB

Sale price£13.15For 1
£15.78 Including VAT
Free delivery on orders over £100
£6.95 Delivery on orders under £100

Fast Delivery

Eaton EMCH163 63A, 10kA, Type C Single Pole MCB

Product Description

  • Terminal Type: Box clamp

  • Current Rating: 63A

  • Tripping Characteristics: Type C

  • Breaking Capacity at Maximum Voltage Rating: 10 kA

  • Reset Actuator Type: Toggle Switch

  • Break Time: Instantaneous

  • Terminal Capacity: 1 -25mm²

  • Terminal Screw: M5 Combination

  • Terminal Torque: 2.0Nm - 2.4Nm max

  • Mounting: DIN rail

  • Degree of Protection: IP20

  • Positive Contact Indication: Red/Green flag indicator

  • Rated Volume: 230/240 V AC, 48V DC (per pole)

  • Rated Impulse and Withstand VOltage: 4kV (1.2/50) u sec

  • Rated Short Circuit Capacity: 10kA to IEC EN 60898 and 15kA to IEC EN 60947-2

  • Selectivity Class: 3 to EN 60898

  • Instanteneous Tripping Current: 3 In < Imt< 5 In

  • Conventional Non-Tripping Current: I nt = 1.45 In

  • Ref/Calibration Temperature: 40° C

  • Number of Operating Cycles Elec: >4000

  • Number of Operating Cycles Mech: >2000
