Hager ADA125U 25A, 1-Pole, 10kA B-Curve, Type A RCBO

Hager ADA125U 25A, 1-Pole, 10kA B-Curve, Type A RCBO


Sale price£42.64For 1
£51.17 Including VAT
Free delivery on orders over £100
£6.95 Delivery on orders under £100

Fast Delivery

Hager ADA125U 25A, 1-Pole, 10kA B-Curve, Type A RCBO

Product Details

  • Neutral position: right

  • Number of poles: 1P

  • Fixing mode: DIN rail type O (symmetrical)

  • Curve: B

  • Rated operational voltage Ue: 230 V

  • Frequency: 50 Hz

  • Rated current: 25A

  • Type of supply voltage: AC

  • Rated insulation voltage: 250 V

  • Max operating voltage: 253 V

  • Rated impulse withstand voltage: 4000 V

  • Rated residual operating current: 30 mA

  • Breaking and opening capacity: 10 kA

  • Dimensions (HxWxD): 110 x 17.5 x 70 mm

  • Total power loss under IN: 6.9 W

  • Electric endurance in number of cycles: 2000

  • Number of mechanical operations: 2000

  • Standard text
    • EN 61009-1
    • IEC 61009-2-2

  • Protection index: IP IP20

  • Residual current type: A

  • Operating temperature: -20…70 °C

Specification

Depth

70mm

Gtin

3250611045359

Height

110mm

Internal external

Internal

Product type

Cons. Unit RCBOs

Width

17.5mm
