Hager NDN350A 50A, 3-Pole, 10kA-15kA, D-Curve Type AC MCB

Hager NDN350A 50A, 3-Pole, 10kA-15kA, D-Curve Type AC MCB


Sale price£41.14For 1
£49.37 Including VAT
Free delivery on orders over £100
£6.95 Delivery on orders under £100

Fast Delivery

Hager NDN350A 50A, 3-Pole, 10kA-15kA, D-Curve Type AC MCB

Technical Details

  • Number of Poles: 3

  • Number of Modules: 3

  • Curve: D

  • Type: AC

  • Rating current: 50A

  • Dimensions (HxWxD): 83 x 52.5 x 70mm

  • Rated Frequency: 50/60 Hz

  • Rated insulation voltage: 500 V

  • Rated impulse withstand voltage: 6000 V

  • Rated service breaking capacity Ics AC according IEC 60898-1: 7.5 kA

  • Rated short circuit breaking capacity Icn under 230V AC according IEC60898-1: 10 kA

  • Total power loss under IN: 15.4 W

  • Standard text:
    • EN 60898-1
    • IEC 60947-2

  • European directive WEEE: concerned

  • Electric endurance in number of cycles: 4000

  • Number of mechanical operations: 20000

  • Protection index IP: IP20

Specification

Depth

70mm

Enclosure material

Metal

Flexible configuration

No

Gtin

3250614619298

Height

83mm

Internal external

Internal

Populated

No

Product type

MCB Units

Width

52.5mm
