Key Features

• MID Certified

• IEC Class 1

• 100A, 50Hz

• Emergency credit

• Silent low credit warning

• Tamper resistance

• IP54

• PayPoint vending of power codes

Technical Details

• Wiring Mode: 3P4W L1L1L2L2L3L3NN

• Basic Current (Ib): 5A

• Basic Current (Imax): 100A

• Starting Current (0.4% Ib): 20mA

• Nominal Voltage (Un): 3 x 230/400V

• Woking Voltage Range: 80% Un ~ 120%Un

• Rated Frequency (fn): 50Hz ± 5%

• Accuracy Class: Active: Active IEC Class 1.0 | Reactive IEC Class 2.0

• Pulse Constant: Active 1000imp/kWh | Reactive 1000imp/kvarh


• Voltage Circuit Power Consumption: ≤2W 10VA

• Current Circuit Power Consumption: ≤4VA

• Working Temperature: -25ºC～70ºC
