WX12 is an intake / extract wall fan suitable for installations in pubs, restaurants, offices, kitchens, factories, schools and shops.

The fan comes complete with a corrugated plastic wall liner and is suitable for installations of wall thickness  275 to 375mm.

WX12 has a 2 speed extract rate of 1162 and 1715 m3/hr and a 2 speed intake rate of 815 & 969 m3/hr. Reversing the fan is achieved with a FR22/30 controller.

The fan includes a silent integral electro-thermal shutter to prevent backdraughts

For safety, a finger-guard is integrated into the ultra-slim high gloss ABS fascia and the exterior wall grille design. The fan includes a positive plug and socket assembly provides a means of isolation.

Technical Specifications:

• Protection (IPX) Rating : IPX4
• Product Model Number : WX12
• Warranty / Guarantee : 2 years
• Depth : 500.00
• Height : 520.00
• Width : 235.00
• Weight : 8.03
• Humidistat Type : No
• IP Rating : 4
• Timer : No
